RolliBot RolliCool 208 Portable AC with Heater User Manual
2.3 – Control Panel
The 208 features an LED control panel which turns on when the unit turns on and includes
buttons.
Buttons & Parts
HEAT
WATER FULL
POWER
WIFI
DEHUM
SLEEP
HIGH
LOW
TIMER
COOL
FAN
88
1 2 3 4 5 6 7 8
1
Timer Button: Press to turn timer mode on or o .
2
Fan Button: Press to turn on fan mode and cycle through 2 fan speeds.
3
Up Button: Press to raise temperature or adjust timer duration.
4
Display: This section will light up to show temperature.
5
Down Button: Press to lower temperature or adjust timer duration.
6
Sleep Button: Press to turn sleep mode on or o .
7
Mode Button: Press to cycle between cool, dehumidify, fan, and heat modes.
8
Power Button: Press to turn the unit on or o .
Scheduling can be done and/or adjusted via the control panel, remote, or the app. See the following section for more
information about the remote. See Section 4 for information about the app.
6
7
8
9
10
11
13
6
Upper Filter
7
Power Cord Fixture
8
Lower Filter
9
Lower Drainage Opening
10
Handle
11
Upper Drainage Opening
12
Air Vent
13
Power Cord
