Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
120
Specifications and Reference Data
Packing gland – required for Flo-Tap models
Packing gland material
Rod material Packing material
J
(4)
Stainless Steel packing gland/cage nipple Carbon Steel PTFE
K
(4)
Stainless Steel packing gland/cage nipple Stainless Steel PTFE
L
(4)
Stainless Steel packing gland/cage nipple Carbon Steel Graphite
N
(4)
Stainless Steel packing gland/cage nipple Stainless Steel Graphite
R Alloy C-276 packing gland/cage nipple Stainless Steel Graphite
Isolation valve for Flo-Tap models
0 Not Applicable or customer supplied ★
1 Gate Valve, Carbon Steel
2 Gate Valve, Stainless Steel
5 Ball Valve, Carbon Steel
6 Ball Valve, Stainless Steel
Temperature measurement
T Integral RTD – not available with flanged model greater than class 600# ★
0 No temperature sensor ★
R Remote thermowell and RTD
Transmitter connection platform
3 Direct-mount, Integral 3-valve Manifold– not available with flanged model greater than class 600 ★
5 Direct -mount, 5-valve Manifold – not available with flanged model greater than class 600 ★
7 Remote-mount NPT connections (
1
/2-in. NPT) ★
6 Direct-mount, high temperature 5-valve Manifold – not available with flanged model greater than class 600
8 Remote-mount SW connections (
1
/2-in.)
Differential pressure range
1 0 to 25 inH
2
O (0 to 62,16 mbar) ★
2 0 to 250 inH
2
O (0 to 621,60 mbar) ★
3 0 to 1000 inH
2
O (0 to 2,48 bar) ★
Transmitter output
A
(5)
4–20 mA with digital signal based on HART Protocol ★
F FOUNDATION Fieldbus Protocol ★
W
(6)
PROFIBUS
®
PA Protocol ★
X
(7)
Wireless (requires wireless options and engineered polymer housing) ★
M
(8)
Low-Power, 1-5 Vdc with digital signal based on HART Protocol
Table 6. Rosemount 3051CFA Annubar Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
