Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
121
Specifications and Reference Data
Transmitter housing material Conduit entry size
A Aluminum
1
/2-14 NPT ★
B Aluminum M20 ⫻ 1.5 ★
J SST
1
/2-14 NPT ★
K SST M20 ⫻ 1.5 ★
P
(9)
Engineered polymer No conduit entries ★
D
(10)
Aluminum G
1
/2
M
(10)
SST G
1
/2
Transmitter performance class
1 1.6% flow rate accuracy, 8:1 flow turndown, 5-yr. stability ★
Wireless options (requires wireless output code X and Engineered Polymer housing code P)
Wireless transmit rate, operating frequency, and protocol
WA3 User configurable transmit rate, 2.4GHz WirelessHART ★
Antenna and SmartPower
WP5 Internal antenna, compatible with Green Power Module (I.S. Power Module sold separately) ★
HART Revision configuration
(5)
(requires HART Protocol output code A)
HR5 Configured for HART Revision 5 ★
HR7 Configured for HART Revision 7 ★
Options (include with selected model number)
Extended product warranty
WR3 3-year limited warranty ★
WR5 5-year limited warranty ★
Pressure testing
(11)
P1 Hydrostatic testing with certificate
PX Extended hydrostatic testing
Special cleaning
P2 Cleaning for special services
PA Cleaning per ASTM G93 level D (Section 11.4)
Material testing
V1 Dye penetrant exam
Material examination
V2 Radiographic examination
Table 6. Rosemount 3051CFA Annubar Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
