Appendix A: Specifications and Reference Data
September 2015
169
Specifications and Reference Data
Materials conformance
(16)
J5 NACE MR-0175/ISO 15156
Country certification
J6 European Pressure Directive (PED) ★
J1 Canadian Registration Certificate
Instrument valves for remote mount option
G2
1
/2-in. Needle valves, SS ★
G6
1
/2-in. OS&Y gate valve, SS ★
G1
1
/2-in. Needle valves, CS
G3
1
/2-in. Needle valves, Alloy C-276
G5
1
/2-in. OS&Y gate valve, CS
Instrument valve options
(17)
DV Double instrument valves (4 valves total) ★
Special shipment
Y1 Mounting hardware shipped separately ★
Assemble mounting hardware
(18)
WP Assemble weldolet to packing body
Special dimensions
VM Variable mounting
585 Packing gland plug
(18)
TP Packing gland plug for steam blow down
585 Installation alignment bar
(18)
A1 Installation alignment bar
Typical model number:585MSL120JHW44000T00800
1. Required for Annubar sensor type F.
2. Required for Annubar sensor type G.
3. Required for Annubar sensor type L.
4. Not available with Annubar sensor type L.
5. Not available with Annubar sensor type G.
6. Not available with sensor material K.
7. Mounting flange bolting and gasket option code 0 must be selected.
8. Mounting flange gasket material option code 2 or 0 must be selected.
9. Not available with ANSI 2500 mounting pressure class.
10. Not available with mounting pressure class N, T, or F.
11. Not available with sensor material W.
12. Not available with sensor material H or W.
13. Applies to flow element only, mounting not tested.
14. If selected with Annubar sensor type F, mounting flange gasket material option code 3 must be selected.
15. For pressure retaining parts only, isolation and instrument valves are not included.
16. Materials of Construction comply with metallurgical requirements within NACE MR0175/ISO 15156 for sour oil field production environments.
Environmental limits apply to certain materials. Consult latest standard for details. Selected materials also conform to NACE MR0103 for sour refining
environments.
17. Only available if Instrument Valves for remote mount option are selected.
18. Only available with Annubar sensor type L.
Table 19. Rosemount 585 Annubar Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
