2 DN50/ PN100 4.30 (109.2) 14.25 (362.0) 22.78 (578.6) 9.00 (228.6) 7.05 (179.1)
3 3 – 150# 4.63 (117.6) 17.50 (444.5) 26.03 (661.2) 9.00 (228.6) 7.55 (191.8)
3 3 – 300# 5.00 (127.0) 17.50 (444.5) 26.03 (661.2) 9.00 (228.6) 7.93 (201.3)
3 3 – 600# 5.38 (136.7) 17.50 (444.5) 26.03 (661.2) 9.00 (228.6) 7.93 (201.3)
3 DN80/PN16 3.85 (97.8) 17.50 (444.5) 26.03 (661.2) 9.00 (228.6) 7.93 (201.3)
3 DN80/PN40 4.16 (105.7) 17.50 (444.5) 26.03 (661.2) 9.00 (228.6) 7.93 (201.3)
3 DN80/ PN100 4.95 (125.7) 17.50 (444.5) 26.03 (661.2) 9.00 (228.6) 7.93 (201.3)
Dimensions are in inches (millimeters).
Table 32. 3051SFA Flange-Lok Annubar Flowmeter Dimensional Data
Sensor size Flange size and rating
A ± 0.125
(3.2)
B ± 0.25
(6.4)
C (Max) D (Max) E (Max)
