Specifications and Reference Data
3 3 – 150# 4.63 (117.6) 17.50 (444.5)
3 3 – 300# 5.00 (127.0) 17.50 (444.5)
3 3 – 600# 5.38 (136.7) 17.50 (444.5)
3 DN80/PN16 3.85 (97.8) 17.50 (444.5)
3 DN80/PN40 4.16 (105.7) 17.50 (444.5)
3 DN80/ PN100 4.95 (125.7) 17.50 (444.5)
Dimensions are in inches (millimeters).
Table 47. Flange-Lok 485 Annubar Primary Element Dimensional Data
Sensor size Flange size and rating A ± 0.125 (3.2) B ± 0.25 (6.4)
