Reference Manual
00809-0100-4809, Rev DA
Appendix B: Product Certifications
September 2015
216
Product Certifications
Special Conditions for Safe Use (X):
1. If the equipment is fitted with the optional 90 V
transient suppressor, it is incapable of withstanding the
500 V isolation from earth test and this must be taken
into account during installation.
2. The enclosure may be made of aluminum alloy and
given a protective polyurethane paint finish; however,
care should be taken to protect it from impact or
abrasion if located in a Zone 0 environment.
IG IECEx FISCO
Certificate: IECEx BAS 08.0025X
Standards: IEC 60079-0: 2011, IEC 60079-11: 2011
Markings: Ex ia IIC T4 Ga, T4(-60 °C 
 T
a
 +70 °C)
N7 IECEx Type n
Certificate: IECEx BAS 08.0026X
Standards: IEC 60079-0: 2011, IEC 60079-15: 2010
Markings: Ex nA IIC T5 Gc, (-40 °C 
 T
a
 +70 °C)
Special Condition for Safe Use (X):
1. If fitted with a 90 V transient suppressor, the equipment
is not capable of withstanding the 500 V electrical
strength test as defined in Clause 6.5.1 of IEC
60079-15:2010. This must be taken into account during
installation.
Brazil
E2 INMETRO Flameproof
Certificate: CEPEL 03.0140X [Mfg USA, Singapore,
Germany], CEPEL 07.1413X [Mfg Brazil]
Standards: ABNT NBR IEC 60079-0:2008,
ABNT NBR IEC 60079-1:2009,
ABNT NBR IEC 60529:2009
Markings: Ex d IIC T* Ga/Gb, T6(-40 °C 
 T
a
 +65 °C),
T5(-40 °C 
 T
a
 +80 °C), IP66*
Special Conditions for Safe Use (X):
1. For ambient temperature above 60 °C, cable wiring
must have minimum isolation temperature of 90 °C, to
be in accordance to equipment operation temperature.
2. The device contains a thin wall diaphragm. Installation,
maintenance and use shall take into account the
environmental conditions to which the diaphragm will
be subjected. The manufacturer's instructions for
installation and maintenance shall be followed in detail
to assure safety during its expected lifetime.
I2 INMETRO Intrinsic Safety
Certificate: NCC 12.1158X [Mfg Brazil, USA, Germany]
Standards: ABNT NBR IEC 60079-0:2013,
ABNT NBR IEC 60079-11:2009,
ABNT NBR IEC 60079-26:2008
Markings: Ex ia IIC T4 Ga, T4(-60 °C 
 T
a
 +70 °C), IP66*
Special Conditions for Safe Use (X):
1. If the equipment is fitted with the optional 90 V
transient suppressor, it is incapable of withstanding the
500 V isolation from earth test and this must be taken
into account during installation.
2. For processes with temperatures above 135 °C, the user
must assess whether the SuperModule temperature
class is suitable for such applications, because in this
situation there is a risk of the SuperModule temperature
being above T4.
China
E3 China Flameproof and Dust Ignition-proof
Certificate: 3051SMV: GYJ14.1039X
[Mfg USA, China, Singapore]
3051SFx: GYJ11.1711X
[Mfg USA, China, Singapore]
Standards: 3051SMV: GB3836.1-2010,
GB3836.2-2010,
GB3836.20-2010
3051SFx: GB3836.1-2010,
GB3836.2-2010,
GB3836.20-2010,
GB12476.1-2000
Markings: 3051SMV: Ex d IIC T6/T5 Ga/Gb
3051SFx: Ex d IIC T6/T5 Ga/Gb;
DIP A20 TA105 °C; IP66
Special Conditions for Safe Use (X):
1. Symbol “X” is used to denote specific conditions of use:
For information on the dimensions of the flameproof
joints the manufacturer shall be contacted.
2. The relationship between T code and ambient
temperature range are as follows:
Parameters
FISCO
Voltage U
i
17.5 V
Current I
i
380 mA
Power P
i
5.32 W
Capacitance C
i
0
Inductance L
i
0
Parameters
HART
FOUNDATION
Fieldbus
SuperModule
only
RTD
(for
3051SFx)
Voltage U
i
30 V 30 V 7.14 V 30 V
Current I
i
300 mA 300 mA 300 mA 2.31 mA
Power P
i
1 W 1.3 W 887 mW 17.32 mW
Capacitance C
i
14.8 nF 0 0.11 uF 0
Inductance L
i
0 0 0 0
T code Ambient temperature range
T6 -50 °C ～ +65°C
T5 -50 °C ～ +80°C
