Reference Manual
00809-0100-4809, Rev DA
Appendix B: Product Certifications
September 2015
215
Product Certifications
IA ATEX FISCO
Certificate: Baseefa08ATEX0064X
Standards: EN 60079-0: 2012, EN 60079-11: 2012
Markings: II 1 G Ex ia IIC T4 Ga,
T4(-60 °C 
 T
a
 +70 °C)
ND ATEX Dust
Certificate: BAS01ATEX1374X
Standards: EN 60079-0: 2012, EN 60079-31: 2009
Markings: II 1 D Ex ta IIIC T105°C T
500
95 °C Da,
(-20 °C   T
a
 +85 °C), V
max
= 42.4 V
Special Conditions for Safe Use (X):
1. Cable entries must be used which maintain the ingress
protection of the enclosure to at least IP66.
2. Unused cable entries must be filled with suitable
blanking plugs which maintain the ingress protection of
the enclosure to at least IP66.
3. Cable entries and blanking plugs must be suitable for
the ambient temperature range of the apparatus and
capable of withstanding a 7 J impact test.
4. The SuperModule(s) must be securely screwed in place
to maintain the ingress protection of the enclosure(s).
N1 ATEX Type n
Certificate: Baseefa08ATEX0065X
Standards: EN 60079-0: 2012, EN 60079-15: 2010
Markings: II 3 G Ex nA IIC T4 Gc,
(-40 °C 
 T
a
 +70 °C), V
max
= 45 V
Special Condition for Safe Use (X):
1. If fitted with a 90V transient suppressor, the equipment
is not capable of withstanding the 500V electrical
strength test as defined in Clause 6.5.1 of EN
60079-15:2010. This must be taken into account during
installation.
International
E7 IECEx Flameproof and Dust
Certificate: IECEx KEM 08.0010X (Flameproof)
Standards: IEC 60079-0:2011, IEC 60079-1: 2007,
IEC 60079-26:2006 (3051SFx models with
RTD are certified to IEC 60079-0:2004)
Markings: Ex d IIC T6…T4 Ga/Gb,
T6(-60 °C   T
a
 +70 °C),
T5/T4(-60 °C 
 T
a
 +80 °C)
Special Conditions for Safe Use (X):
1. The device contains a thin wall diaphragm. Installation,
maintenance and use shall take into account the
environmental conditions to which the diaphragm will
be subjected. The manufacturer's instructions for
installation and maintenance shall be followed in detail
to assure safety during its expected lifetime.
2. For information on the dimensions of the flameproof
joints the manufacturer shall be contacted.
Certificate: IECEx BAS 09.0014X (Dust)
Standards: IEC 60079-0:2011, IEC 60079-31:2008
Markings: Ex ta IIIC T105 °C T
500
95 °C Da,
(-20 °C   T
a
 +85 °C), V
max
= 42.4V
Special Conditions for Safe Use (X):
1. Cable entries must be used which maintain the ingress
protection of the enclosure to at least IP66.
2. Unused cable entries must be filled with suitable
blanking plugs which maintain the ingress protection of
the enclosure to at least IP66.
3. Cable entries and blanking plugs must be suitable for
the ambient temperature range of the apparatus and
capable of withstanding a 7 J impact test.
4. The 3051S- SuperModule must be securely screwed in
place to maintain the ingress protection of the
enclosure.
I7 IECEx Intrinsic Safety
Certificate: IECEx BAS 08.0025X
Standards: IEC 60079-0: 2011, IEC 60079-11: 2011
Markings: Ex ia IIC T4 Ga, T4(-60 °C 
 T
a
 +70 °C)
Parameters
FISCO
Voltage U
i
17.5 V
Current I
i
380 mA
Power P
i
5.32 W
Capacitance C
i
0
Inductance L
i
0
Temperature class Process temperature
T6 -60 °C to +70 °C
T5 -60 °C to +80 °C
T4 -60 °C to +120 °C
Parameters
HART
FOUNDATION
Fieldbus
SuperModule
only
RTD
(for
3051SFx)
Voltage U
i
30 V 30 V 7.14 V 30 V
Current I
i
300 mA 300 mA 300 mA 2.31 mA
Power P
i
1 W 1.3 W 887 mW 17.32 mW
Capacitance C
i
14.8 nF 0 0.11 uF 0
Inductance L
i
0 0 0 0
