DR.
SIZE
C
TITLE
BOULDER, COLORADO
DRAWING NO.
APPROVAL
SPECIALS
TAGGING
DRAWING
*ALL DIMENSIONS ARE NOMINAL
AND ARE FOR REFERENCE ONLY
*UNLESS OTHERWISE SPECIFIED
DIMENSIONS IN INCHES (MM)
TYPE I
SHEET:
of
SCALE
: NONE
REVISION
ECO NO.
APP'D
DATE
REVISION TABLE
DESCRIPTION
P DEEGAN
12/13/11
S IFFT
12/27/11
00405-1001
6
7
DIMENSIONAL DRAWING MODEL 405
COMPACT FLOWMETER
2/24/14JSDSI1051961AQ
REMOVE BETA CALLOUT FROM NOTE 6
REMOTE MOUNT MANIFOLD TYPE
CONNECTION OPTIONS
3051S TRANSMITTER
SHOWN
305 3-VALVE
MANIFOLD
3 VALVE / PIPE MOUNT
ISOLATION
VALVE
EQUALIZER
VALVE
ISOLATION
VALVE
1/4" NPT
MANIFOLD
VENTS
1/4" NPT
MANIFOLD
VENTS
PIPE MOUNTING
CONFIGURATION
1/2" NPT
PROCESS
CONNECTIONS
3051S TRANSMITTER
SHOWN
305 5-VALVE
MANIFOLD
5 VALVE / PANEL MOUNT
EQUALIZER
VALVE
ISOLATION
VALVE
TEST/VENT
VALVE
TEST/VENT
VALVE
ISOLATION
VALVE
1/4" NPT VENT
CONNECTION
1/4" NPT VENT
CONNECTION
1/2" NPT
PROCESS
CONNECTIONS
PANEL MOUNTING
CONFIGURATION
