Rosemount 3051SFA - Page 264

Reference Manual
00809-0100-4809, Rev DA
Appendix B: Product Certifications
September 2015
256
Product Certifications
®
DR.
SIZE
C
TITLE
BOULDER, COLORADO
DRAWING NO.
APPROVAL
SPECIALS
TAGGING
DRAWING
*ALL DIMENSIONS ARE NOMINAL
AND ARE FOR REFERENCE ONLY
*UNLESS OTHERWISE SPECIFIED
DIMENSIONS IN INCHES (MM)
TYPE I
SHEET:
of
SCALE
: NONE
REVISION
ECO NO.
APP'D
DATE
REVISION TABLE
DESCRIPTION
1.10 [27,9]
.85 [21,6]
1.10 [27,9]
P DEEGAN
12/13/11
S IFFT
12/27/11
00405-1001
5
7
DIMENSIONAL DRAWING MODEL 405 COMPACT FLOWMETER
2/24/14JSDSI1051961AQ
REMOVE BETA CALLOUT FROM NOTE 6
REMOTE MOUNT
CONNECTION TYPE
(405A)
REMOTE MOUNT TYPE
CONNECTION OPTIONS
R3 OPTION
NOTE: USED FOR BOTH 1/4" NPT
& 1/2" NPT REMOTE INSTRUMENT
CONNECTION
R3 WITH E OPTION
NOTE: USED ONLY FOR
1/2" NPT REMOTE INSTRUMENT
CONNECTION
REMOTE MOUNT
CONNECTION TYPE
(405C/P)
MULTIPLE
MOUNTING
ORIENTATIONS
R3 OPTION NOTE: ONLY 1/2" NPT REMOTE INSTRUMENT CONNECTION AVAILABLE
MULTIPLE
MOUNTING
ORIENTATIONS
8.
8.
