Seite - 9 -
04.10.2008 / LSV-JWh/ Rev. 02
DIGIDOS 24 AT
© 2008
BESCHREIBUNG
Hauptbauteile
2 BESCHREIBUNG
2.1 Hauptbauteile der DIGIDOS
HECKDISPLAY
Schaltkasten
Gleichstrommotor Schaummittelpumpe
Schaummittelmengenmessung
Konsole
MESSSTRECKE MIT DURCH-
FLUSSMESSER
Einspritzpunkt mit
Rückschlagventil
Schaummittel Durchflussmesser
Rückschlagventil
Wasser
