3–6 • Maintenance XPression Prime Maintenance Guide (v01)
4. Disconnect the XPression Prime system from the drives.
5. Using a Phillips head screwdriver, remove the two screws located on the top of the drive cage at the front of the
XPression Prime system.
Do not remove the black screws and grommets located on the drive cage.
6. Gently lift the drive cage from the XPression Prime system.
