3.2.3 Selecting Keypad Transmission Format
There are seven keypad transmission formats.
More information on each of the keypad transmission formats is
presented in Section 3.2.3.1.
Only one keypad transmission format can be active at any one time.
To select the keypad transmission format:
1. Enter Programming mode.
2. Press 1 to enter Menu 1.
The left LED turns red.
3. Enter one of the following options:
1 – Single Key, Wiegand 6-Bit (Rosslare Format) (default)
2 – Single Key, Wiegand 6-Bit with Nibble + Parity Bits
3 – Single Key, Wiegand 8-Bit, Nibbles Complemented
4 – 4 Keys Binary + Facility Code, Wiegand 26-Bit
5 – 1 to 5 Keys + Facility Code, Wiegand 26-Bit
6 – 6 Keys BCD and Parity Bits, Wiegand 26-Bit
8 – 1 to 8 Keys BCD, Clock & Data Single Key
When selecting Option 8, the right LED turns orange and an
additional input is required to specify the number of keys in
the PIN code.
You hear three beeps.
The system returns to Standby mode.
