Rosslare AYC-Q54B - Defining the Auxiliary Input and Output

Controller Functionality
AYC-Qx4 family manual Page 41
4) System returns to its normal mode.
• You will hear three beeps.
• The Door LED will turn
off.
• The Mode LED will turn
green.
Note:
• Default value is 0004 which corresponds to Fail Secure
operation, no siren, and 4-seconds Lock Strike release time.
Defining the Auxiliary Input and Output
The default auxiliary setting is 2004.
1) Enter the Programming
Mode.
2) Press 6 to enter Menu 6.
• The Mode LED will flash
green
3) Construct a code using the instructions below.
Auxiliary Mode
Auxiliary Setting
Auxiliary Mode
In addition to the Lock Strike Relay and Lock Strike REX, the
AYC-Qx4 features an Auxiliary Input. The Auxiliary Mode defines
the function of the Auxiliary Input.
Auxiliary Settings
Each of the Auxiliary Modes has a two digit setting that affects
how the Auxiliary Mode functions.
6
2 ? ? ?
Mode/Transmit
Door/Program
Green
Mode/Transmit
Door/Program
Green
Mode/Transmit
Door/Program
Green
Green
