Technical Specifications
AYC-Qx4 family manual Page 7
2. Technical Specifications
Specifications AYC-Q54B AYC-Q64B
Electrical Characteristics
Power supply type Linear type – recommended
Operating voltage range 5 - 16VDC (when used as a
controller, provided by the secure
application appurtenance)
Input current standby
(12VDC)
65mA 90mA
Input current max (16VDC) 110mA 130mA
LED control input Dry contact N.O.
Tamper output Open collector, active low, 30mA
max sink current
Cable distance to host
controller
Up to 500ft (150 meters) using an
18AWG cable
Max proximity card read
range*
N/A 1.77 inches
(45mm)
Proximity card modulation N/A ASK at 125 KHz
Proximity card compatibility N/A EM cards
Card Transmit format
(Reader)
N/A 26-bit Wiegand,
or Clock & Data
Keypad Transmit Format
(Reader)
Programmable PIN code formats
LED indicators Two tri-colored LEDs
Communication Data1/C1, Data0/C2—open
collector, 5V termination
