15
Min 1m Min 1m
3.2 General workow
• After determining the vehicle data , the vehicle is
driven over the platform.
• the manufacturer-approved pick-up points on the
vehicle are selected and the matching supports
are placed underneath. After checking that the
weight distribution is correct, the vehicle is lifted
by the scissor lift
• The vehicle is raised to the desired height with
the scissor lift.
• After completion of the work, the vehicle is low-
ered again to the ground and driven off.
3.3 Work area, danger zones
Figure 4: Work area, Danger zones
1. Control area
2. Work area and danger zone
3. Vehicle overhang
Risk of injury in the danger zone of the
scissor lift in the event of incorrect
behavior.
Only remain in the danger area if you
have been trained and briefed and
assigned to the area.
Keep the work area clean.
Keep escape routes clear so that you
can leave the danger zone quickly
and safely in the event of an emer-
gency.
②
①
③
Min H : 5m
4
