Rotary DS35EX User Manual

57
Detail for PB-DS35EX01
PartNo. Description Qty
1 B201-10*65 Hex socket head screw M10*65 4
2 B21-4*6 Hex socket set screw with at pointM4*6 2
3 B21-6*10 Hex socket set screw with at pointM6*10 14
4 B25-6*12 Hex socket pan head screw M6*12 8
5 B25-6*80 Hex socket pan head screw M6*80 4
6 B25-8*20 Hex socket pan head screw M8*20 4
7 B30-6 Hex NutM6 4
8 B30-10 Hex Nut M10 4
9 B41-24 Flat washer Φ24 4
11 B63-25 Circlip Φ25 8
12 FJ7352-3 Fitting for cylinder 2
13 XG120028 Extension beam Handle 2
14 XG130044 M6*10 set screw-cone point 8
15 XG130075 Proximity switch 3
16 XX110003 Ramp assembly 2
17 XX11006 Kicker assembly 2
18 XX120002G Base frame weldment 2
19 XX120003G Scissor leg weldment 2
20 XX120004G Scissor leg weldment 2
21 XX120005 Scissor leg weldment 2
22 XX120006 Scissor leg weldment 2
23 XX120014G Platform weldment 2
24
XX120036G Extension beam (Picture show) 1
XX120013G Extension beam (do not show) 1
25 XX130080 Pin long 2
26 XX130081 Pin long 4
27 XX130082 Lower cylinder pin 4
28 XX130086 Upper cylinder pin 2
29 XX130210 Cushion weldment 2
30 XX130214 Pin 2
31 XX130225 Stainless plate 2
32 XX130226G Beam stop bolt 2
33 XX130232 Cylinder cover
2
34 XX130233 Connect plate 4
35 XX130261 Base ramp weldment 2
36 XX140007 Slider block (lower) 4
37 XX140008 Slider block(Upper) 4
38 XX140010 Cylinder 2
39 XX140011 Cylinder 2
40 XX140014Y Bearing 25dia*25 long 8
