User manual
Wired control - ORIS
EN
No. Denition Description
9 T3 value ODU coil temp.
10 T4 value OAT
11 TP value Discharged temp.
12 T7 value
Temp. of refrigerant for PCB cool
13 EVX opening degree Actually value
14 ODU fan motor speed -
15 AC current -
16 AC voltage -
17 IPM temp. (T9) Compressor module temp.
18
Limitation reason of
compressor frequency
0: no limitation;
1: T3B temp. limitation (reserved);
2: OAT limitation;
4: Discharged temp. limitation;
8: Voltage limitation
16: Current limitation
32: IPM temp’ limitation
64: Night mode limitation
128: LWT limitation
If occur multi limitation, display value=sum of all limitation value
19
Limitation reason of
compressor frequency
0: no limitation;
1: Limitation of dierent value between EWT&LWT
20 Tw_in value EWT
21 Tw_out value LWT of BPHE
22 T1 value LWT of unit (after the EHs inside the unit)
23 T6 value IAT, the sensor built inside the wired controller
24 T5 value DHW value
25 Tw-2 value Second zone EWT value when set this function (reserved)
26 T1B value External heat source (boiler) LWT value
27 Capacity demand -
28 Inv. Pump speed -
29 Last alarm
-
30 Penult alarm -
