16 Technical data
Installer reference guide
102
RVLQ05+08CAV4 + RHYHBH05AA + RHYHBH/X08AA +
RHYKOMB33AA
ROTEX HPU hybrid
4P355635-1 – 2013.05
16.5 Technical specifications
16.5.1 Technical specifications: Outdoor unit
Nominal capacity and nominal input
Heating only type Reversible type
Outdoor units RVLQ05CAV3 RVLQ08CAV3 RVLQ08CAV3
Indoor units RHYHBH05 RHYHBH08 RHYHBX08
Condition 1
(a)
Heating capacity Minimum 1.80 kW
Nominal 4.40 kW 7.40 kW
Maximum 5.12 kW 10.02 kW
Cooling capacity Minimum — 2.50 kW
Nominal — 6.86 kW
Maximum —
Heating PI Nominal 0.87 kW 1.66 kW
Cooling PI Nominal — 2.01 kW
COP Nominal 5.04 4.45
EER Nominal — 3.42
Condition 2
(b)
Heating capacity Minimum 1.80 kW
Nominal 4.03 kW 6.89 kW
Maximum 4.90 kW 9.53 kW
Cooling capacity Minimum — 2.50 kW
Nominal — 5.36 kW
Maximum —
Heating PI Nominal 1.13 kW 2.01 kW
Cooling PI Nominal — 2.34 kW
COP Nominal 3.58 3.42
EER Nominal — 2.29
(a)
In heating: Ambient temperature DB/WB 7°C/6°C – leaving water condenser 35°C (DT=5°C). In cooling: Ambient temperature
35°C – leaving water evaporator 18°C (DT=5°C)
(b)
In heating: Ambient temperature DB/WB 7°C/6°C – leaving water condenser 45°C (DT=5°C). In cooling: Ambient temperature
35°C – leaving water evaporator 7°C (DT=5°C)
