Rotex RVLQ05+08CA - Technical Specifications: Gas Boiler

16 Technical data
Installer reference guide
108
RVLQ05+08CAV4 + RHYHBH05AA + RHYHBH/X08AA +
RHYKOMB33AA
ROTEX HPU hybrid
4P355635-1 – 2013.05
16.5.3 Technical specifications: Gas boiler
RHYKOMB33AA
Function Heating only
Heat pump module RHYHBH05
RHYHBH08
Device category C13, C33, C43, C53, C63,
C83, C93
Destination country – Gas supply
pressure
GB – G20 (20 mbar),
G31 (30~37 mbar)
FR – G20 (20 mbar),
G25 (25 mbar),
G31 (30 mbar)
BE – G20 (20 mbar),
G25 (25 mbar),
G31 (37 mbar)
DE – G20 (20 mbar),
G25 (25 mbar),
G30 (50 mbar)
IT – G20 (20 mbar),
G31 (30 mbar)
Destination country – Gas category GB – II2H3P
FR – II3Esi3P
BE – II2E(s)3P
DE – II2ELL3P
IT – 2H3P
Gas
Gas consumption (G20) 0.78~3.39 m
3
/h
Gas consumption (G25) 0.90~3.93 m
3
/h
Gas consumption (G31) 0.30~1.29 m
3
/h
Nox class 5
Central heating
Thermal load (Hi) G20 (20 mbar) 7.6~27.0 kW
Thermal load (Hi) G25 (25 mbar) 6.2~22.1 kW
Thermal load (Hi) G31 (30/50 mbar) 7.6~27.0 kW
Thermal load (Hi) G31 (37 mbar)
Heating power space heating (80/60)
G20 (20 mbar)
8.2~26.6 kW
Heating power space heating (80/60)
G25 (25 mbar)
6.7~21.8 kW
Heating power space heating (80/60)
G31 (30/50 mbar)
8.2~26.6 kW
Heating power space heating (80/60)
G31 (37 mbar)
Efficiency space heating (net calorific
value 80/60)
98%
Efficiency space heating (net calorific
value 40/30 (30%))
107%
RHYKOMB33AA
Operation range 15~80°C
Domestic hot water
Heating power domestic hot water 7.6~32.7 kW
Efficiency domestic hot water (net
calorific value)
105%
Operation range 40~65°C
Domestic hot water flow rate (setpoint
60°C)
9 l/min
Domestic hot water flow rate (setpoint
40°C)
15 l/min
Casing
Colour White – RAL9010
Material Pre-coated sheet metal
Dimensions
Packing (H×W×D) 820×490×270 mm
Unit (H×W×D) 710×450×240 mm
Machine net weight 36 kg
Packed machine weight 37 kg
Packing material Carton/PP (straps)
Packing material (weight) 1 kg
Main components
Water side heat exchanger Aluminium
Space heating water circuit
Space heating piping connections Ø22 mm
Piping material Cu
Safety valve See manual indoor unit
Manometer Yes
Drain/fill valve No
Stop valve No
Air purge valve Yes
Maximum pressure space heating
circuit
3 bar
Domestic hot water circuit
Domestic hot water piping connections Ø15 mm
Piping material Cu
Gas connection Ø15 mm
Flue gas/combustion air connection Concentric connection
Ø60/100 mm
Electrical
Power supply voltage 230 V
Power supply phase 1~
Power supply frequency 50 Hz
IP class IP44
Maximum electrical power consumption 55 W
Electrical power consumption (standby) 2 W
