7 x Hydraulic system connection
47
FA ROTEX Solaris RPS3 P2 - 06/2012
Short name Meaning Remark Order No.
SCS 538/16/0 Sanicube Solaris 16 45 16
SCS 538/16/7 Sanicube Solaris 16 45 21
SCS 538/16/16 Sanicube Solaris 16 45 17
HYC 343/19/0 HybridCube 14 05 07
HYC 544/19/0 HybridCube 14 05 01
HYC 544/32/0 HybridCube 14 05 02
GSU S GasSolarUnit with solar heating support
GSU 520S-e 15 71 13
GSU 520S F-e 15 71 14
GSU 530S-e 15 71 25
GSU 530S F-e 15 71 26
GSU GasSolarUnit without solar heating support
GSU 320-e 15 70 28
GSU 320 F-e 15 70 29
GSU 535-e 15 71 43
GSU 535 F-e 15 71 48
A1-BO
A1 BO 15 bio-e 15 49 27
A1 BO 20 bio-e 15 49 28
A1 BO 27 bio-e 15 49 29
A1 BO 35 bio-e 15 49 50
A1-BG
A1 BG 25-e 15 59 30
A1 BG 25 F-e 15 59 31
A1 BG 40-e 15 59 40
A1 BG 40F-e 15 59 41
1Cold water
2Hot water
3 Heating inflow
4 Heating return flow
5 Mixer circuit Optional
6 Circulation circuit
7 Check valve, return valve Provided by customer
7a Gravity brake (for cold/hot water connection) Accessories 16 50 70
8 Solar circuit Optional
AMK1 Mixer group Accessories 15 60 44
FLG Solaris FlowGuard regulation valve with flow indicator 16 41 02
FLS20
Flow sensor, Solaris FlowSensor FLS20
(flow and flow temperature measurement)
Accessories 16 41 07
Mi 3-way-mixer with drive motor
Supplied with AMK1.
P
Mi
Mixer circuit pump
P
K
Boiler circuit pump Included in the scope of delivery of the GSU/A1.
P
S1
Tank circulation pump Included in the scope of delivery of the RPS3 P2.
P
S2
Solar panel circulation pump Included with RDS1.
P
Z
Circulation pump Provided by customer
RDS1 Pressure station
Pressurised solar system
16 20 30
RPS3 P2 Mono Solaris control and pump unit 16 41 13
RPWT1 Solaris plate heat exchanger 16 20 31
SK High-performance flat solar panel
Solaris V21P 16 20 12
Solaris V26P 16 20 10
Solaris H26P 16 20 11
SV Safety pressure relief valve
t
AG
Flue gas temperature probe Accessories 15 70 52
t
AU
Outside temperature sensor Supplied with GSU/A1.
t
DHW
Cylinder temperature sensor Supplied with GSU/A1BG+ASA1.
t
V
Heating inflow temperature probe
Supplied with GSU/A1.
t
R
Heating return temperature sensor
t
Mi
Mixer circuit flow temperature sensor Accessories 15 60 62
