Rothenberger ROWELD E Series - Shd450 Shd500 Shd630 Shd800 Shd1000 Shd1200; Applicable Range and Technical Parameter

39
SHD450 SHD500 SHD630 SHD800 SHD1000 SHD1200
1. Applicable Range and Technical Parameter
* The special voltage is based on the actual voltage.
Type
SHD-800
SHD-1000
SHD-1200
Materials
PE， PP， PVDF
Max. range of
diameter
450mm~800 mm
630mm-1000mm
630-1200mm
Ambient temp.
－5～45℃
Power supply
～380 V±10 ％，50 Hz
Total current
28A
43A
60A
Total power
18.2kW
24 kW
29.5 kW
Include：Heating plate
12.5 kW
17.5 kW
21.5 kW
Planing tool motor
2.2 kW
3 kW
4 kW
Hydraulic unit motor
3 kW
3 kW
3 kW
Crane power
0.5KW
0.5KW
1KW
Dielectric resistance
>1MΩ
Max. Pressure
≤16MPa
≤16MPa
≤16MPa
Total section of
cylinders
44cm
2
38.9cm
2
50.7 cm
2
Volume of oil box
4L
Hydraulic oil
270℃
Undesired sound
±5℃
Max. Temperature of
heating plate
40～50（kinematic viscosity)mm
2
/s, 40℃
Difference in surface
temperature of heating
plate
＜70 dB
Weight
1454
2600
4500
