Rothenberger ROWELD E Series - SHDS Series Model Technical Parameters; Applicable Range and Technical Parameters

73
SHDS110 SHDS160A2 SHDS160A4 SHDS160B4 SHDS200A2
SHDS200A4 SHDS200B4
1.Applicable Range and Technical Parameter
Type
SHDS-110
SHDS160A2,SHDS160A4
,SHDS160B4
SHDS200A2,SHDS200A4,
SHDS200B4
Materials
PE, PP, PVDF
Range of diameter
10mm～110mm
50mm～160mm
63mm～200mm
Ambient temp.
-5
～
45
℃
Power supply
220V±10％, 50Hz
Total power
1.4Kw
1.7Kw
2.2Kw
Include: Heating plate
0.7Kw
1Kw
1.5Kw
Planing tool motor
0.7Kw
Max. Temperature of
heating plate
<270
℃
Difference in surface
temperature of
heating plate
±5℃
Max. Pressure
1040N
Weight
39kg
2pcs clamp 46kg,4pcs
clamp 60kg
2pcs clamp 60kg,4pcs
clamp 69kg
* The special voltage is based on the actual voltage.
