Rothenberger ROWELD E Series - SHD160-355 Model Technical Parameters

9
SHD160 SHD250 SHD315 SHD 355
1. Applicable Range and Technical Parameter
Type
SHD-160/63
SHD250/63
SHD315/90
SHD355/90
Materials
PE， PP，PVDF
Max.range of diameter
63~160mm
63~250mm
90~315mm
90~355mm
Ambient temp.
－5～45℃
Power supply
～220V±10
Total current
10A
17.5A
22.1A
26.6A
Total power
2.45KW
3.85KW
4.85KW
5.85KW
Include：Heating plate
1KW
2 KW
3KW
4KW
Planing tool motor
0.7KW IP54
1.1 KW IP54
1.1KW IP54
1.1KW
Hydraulic unit motor
0.75 kW IP54
Dielectric resistance
>1MΩ
Max. Pressure
6 MPa
Total section of
cylinders
6.26 cm
2
10.98 cm
2
20 cm
2
20 cm
2
Volume of oil box
3L
Hydraulic oil
40～50（kinematic viscosity)mm
2
/s, 40℃
Undesired sound
<70 dB
Max.Temperature of
heating plate
270℃
Difference in surface
temperature of heating
plate
±5℃
Weight
106 kg
130 kg
202.6 kg
260 kg
* The special voltage is based on the actual voltage.
