Rothenberger ROWELD E Series - Timer and Temperature Controller

45
4.Timer and Temperature Controller
If one of the parameters is changed, such as outside diameter, SDR or material of pipes, the
soaking time and cooling time should be reset according to the welding standard.
4.1 Timer setting
4.2 Instruction for Use
Press
“set”
The lamp T
2
is on and the lamp T
5
is off
Pressing
△or▽
To set soaking time in second.
Press
“set”
The lamp T
2
is off and the lamp T
5
is on
Press
△or▽
To set cooling time in second
Press
“Set”
Timer setting is over
Press
“T
2
”
Press
“T
5
”
Press
“△”and“▽
”
Alarm when the soaking time counts down to zero.
Alarm when the cooling time counts down to zero
Timer stops
