2. Descriptions
The machine consists of basic frame, hydraulic unit, heating plate, Planing tool, and support.
2.1 Structure
1.Hydraulic
unit
2. Basic frame
3. Support
4. Heating plate
5. Planing
tool
6.Crane
（SHD450-630 optional）
（SHD800-1200 optional）
2.2 Hydraulic Unit
1. Direction valve
2. Pressure regulation valve
3. Pressure gauge
4. Swing check valve
5. Oil tank
6. Power cable
