Rothenberger ROWELD E Series - Page 65

65
SHD630
（
Cylinder area=37.7cm²
）
D（mm)
SDR
e(mm)
P1(bar)
H(mm)
P2(bar)
t1(sec)
t2(sec)
t3(sec)
P3(bar)
t4(min)
315
9
35.0
12.2
3
0.8
350
14
17
12.2
43
11
28.6
10.2
3
0.7
286
13
15
10.2
35
13.6
23.2
8.4
2.5
0.6
232
11
13
8.4
29
17
18.5
6.9
2
0.5
185
10
11
6.9
24
17.6
17.9
6.6
2
0.4
179
9
10
6.6
23
21
15.0
5.6
2
0.4
150
9
10
5.6
20
26
12.1
4.6
2
0.3
121
8
8
4.6
15.5
33
9.5
3.6
1.5
0.2
95
7
7
3.6
12
D（mm)
SDR
e(mm)
P1(bar)
H(mm)
P2(bar)
t1(sec)
t2(sec)
t3(sec)
P3(bar)
t4(min)
355
9
39.4
15.6
3.5
1.0
394
16
19
15.6
48
11
32.3
13.0
3
0.9
323
14
17
13.0
39
13.6
26.1
10.7
3
0.7
261
12
14
10.7
32
17
20.9
8.7
2.5
0.6
209
10
11
8.7
26
17.6
20.2
8.4
2.5
0.6
202
10
11
8.4
25
21
16.9
7.1
2
0.5
169
9
10
7.1
22
26
13.7
5.8
2
0.4
137
8
8
5.8
17
33
10.8
4.6
1.5
0.3
108
7
7
4.6
14
D
（
mm)
SDR
e(mm)
P1(bar)
H(mm)
P2(bar)
t1(sec)
t2(sec)
t3(sec)
P3(bar)
t4(min)
400
9
44.4
19.7
3.5
1.3
444
17
20
19.7
54
11
36.4
16.5
3
1.1
364
15
18
16.5
44
13.6
29.4
13.6
3
0.9
294
13
15
13.6
35
17
23.5
11.1
2.5
0.7
235
11
13
11.1
30
17.6
22.7
10.7
2.5
0.7
227
11
13
10.7
29
21
19.0
9.1
2.5
0.6
190
10
11
9.1
24
26
15.4
7.4
2
0.5
154
9
10
7.4
20
33
12.1
5.9
2
0.4
121
8
8
5.9
16
