Rothenberger ROWELD E Series - Page 67

67
SHD800
（
Cylinder area=44cm²
）
Dmm)
SDR
e(mm)
P1(bar)
H(mm)
P2(bar)
t1(sec)
t2(sec)
t3(sec)
P3(bar)
t4(min)
450
9
50.0
21.4
3.5
1.4
500
19
24
21.4
61
11
40.9
17.9
3.5
1.2
409
16
19
17.9
50
13.6
33.1
14.8
3
1.0
331
14
17
14.8
40
17
26.5
12.0
3
0.8
265
12
14
12.0
33
17.6
25.6
11.6
2.5
0.8
256
12
14
11.6
32
21
21.4
9.8
2.5
0.7
214
10
11
9.8
26
26
17.3
8.0
2
0.5
173
9
10
8.0
22
33
13.6
6.4
2
0.4
136
8
8
6.4
17
Dmm)
SDR
e(mm)
P1(bar)
H(mm)
P2(bar)
t1(sec)
t2(sec)
t3(sec)
P3(bar)
t4(min)
500
9
55.6
26.4
4
1.8
556
20
25
26.4
68
11
45.5
22.1
3.5
1.5
455
18
22
22.1
57
13.6
36.8
18.2
3
1.2
368
15
18
18.2
45
17
29.4
14.8
3
1.0
294
13
15
14.8
35
17.6
28.4
14.3
3
1.0
284
13
15
14.3
34
21
23.8
12.1
2.5
0.8
238
11
13
12.1
30
26
19.2
9.9
2.5
0.7
192
10
11
9.9
24
33
15.2
7.9
2
0.5
152
9
10
7.9
20
Dmm)
SDR
e(mm)
P1(bar)
H(mm)
P2(bar)
t1(sec)
t2(sec)
t3(sec)
P3(bar)
t4(min)
560
9
62.2
33.2
4
2.2
622
22
29
33.2
76
11
50.9
27.7
4
1.8
509
19
24
27.7
62
13.6
41.2
22.9
3.5
1.5
412
16
19
22.9
50
17
32.9
18.6
3
1.2
329
14
17
18.6
40
17.6
31.8
18.0
3
1.2
318
14
17
18.0
39
21
26.7
15.2
3
1.0
267
12
14
15.2
33
26
21.5
12.4
2.5
0.8
215
10
11
12.4
28
33
17.0
9.9
2
0.7
170
9
10
9.9
22
