Rothenberger ROWELD E Series - Welding Parameters for SHD1000-1100 Models

70
D（mm)
SDR
e(mm)
P1(bar)
H(mm)
P2(bar)
t1(sec)
t2(sec)
t3(sec)
P3(bar)
t4(min)
900
9
100.0
96.9
5
6.5
1000
34
35
96.9
121
11
81.8
81.1
4.5
5.4
818
28
35
81.1
100
13.6
66.2
66.8
4
4.5
662
23
32
66.8
80
17
52.9
54.3
4
3.6
529
19
24
54.3
65
17.6
51.1
52.6
4
3.5
511
19
24
52.6
62
21
42.9
44.5
3.5
3.0
429
17
20
44.5
53
26
34.6
36.3
3
2.4
346
14
17
36.3
43
33
27.3
28.8
3
1.9
273
12
14
28.8
33
D
（
mm)
SDR
e(mm)
P1(bar)
H(mm)
P2(bar)
t1(sec)
t2(sec)
t3(sec)
P3(bar)
t4(min)
1000
9
111.1
119.6
5.5
8.0
1111
35
35
119.6
134
11
90.9
100.1
5
6.7
909
30
35
100.1
110
13.6
73.5
82.5
4.5
5.5
735
26
35
82.5
90
17
58.8
67.0
4
4.5
588
21
27
67.0
72
17.6
56.8
64.9
4
4.3
568
20
25
64.9
70
21
47.6
54.9
3.5
3.7
476
18
23
54.9
59
26
38.5
44.8
3.5
3.0
385
15
18
44.8
48
33
30.3
35.6
3
2.4
303
13
15
35.6
36
