What to do if Rotork Controller is unable to fully open or close?
If the Rotork Controller is unable to fully open or close, adjust the cams if they are not set correctly, investigate the valve if there is a bent valve stem, and reset the stop bolts if the stop bolt adjustment is incorrect.
Why does my rotork ROM 1/A motor overheat?
If the Rotork Controller motor overheats, verify the voltage is correct, investigate the valve for tightness, and check the duty-cycle due to a potentially high working frequency. If the voltage is not correct, check it. If the valve is too tight, investigate it. If there is a high working frequency, check the duty-cycle.
Why is my rotork ROM 1/A actuator running in the wrong direction?
If the Rotork Controller actuator runs in the wrong direction, check the remote control circuit for incorrectly connected terminals and change the phase wiring if the 3-phase wiring is incorrect. If wrong terminals are connected, check the remote control circuit. If there is wrong 3-phase wiring, change phase wiring.
What to do if rotork ROM 1/A Controller operates but there is no valve moment?
If the Rotork Controller operates but there is no valve movement, replace the adaptor if the drive adaptor is worn and investigate the valve if there is a broken valve stem.
Why is there erratic operation of multiple Rotork Controllers?
If you experience erratic operation of multiple Rotork Controllers, it might be because multiple actuators are on the same control circuit. Actuators must have individual control circuit.
Key safety instructions and warranty information for the actuator.
Specifies actuator's performance class and duty cycles according to EN standards.
Details that the gear train is lubricated for the life of the actuator.
Verify torque requirements before mounting the actuator.
Specifies material and strength requirements for actuator-to-valve fixing bolts.
Critical safety warning against lifting the combined unit by the actuator.
Procedure for adjusting stop bolts for non-seating valve types to set positions.
Procedure for adjusting stop bolts for seating valve types to set positions.
Crucial safety instruction to isolate power before accessing actuator covers.
Verify that the supply voltage matches the actuator's nameplate rating.
Instructions for preparing cable entries and ensuring waterproof connections.
Connect the earth wire to the designated PE screw for safety.
Details manual operation for ROM 1/A using a hex input drive.
Critical safety warning to isolate power before manual operation.
Describes handwheel operation for ROM 2-6 models, including automatic disengagement.
Caution against using extra levers for handwheel operation to prevent damage.
Explains the function and adjustment of the local valve position indicator.
Details on adjusting travel cams and limit switches to set valve open/closed positions.
Reference to the procedure for adjusting plastic type travel cams on page 9.
Reference to the procedure for adjusting metal cams for ROM 1/A on page 10.
Reference to the procedure for adjusting metal type travel cams on page 11.
Explains output shaft rotation direction relative to the indicator for different ROM models.
Crucial safety warning to isolate power before accessing actuator covers.
Step-by-step guide for setting open and closed positions using plastic cams.
Describes adjustment for anti-clockwise closing valve types with plastic cams.
Information on optional torque switches and their factory settings.
Detailed procedure for adjusting metal cams on ROM 1/A for clockwise closing valves.
Step-by-step guide for adjusting metal cams on ROM 2-6 for clockwise closing valves.
Procedure for adjusting the potentiometer if stop bolts were adjusted or the POT slipped.
Lists common causes and solutions for the motor failing to operate.
Lists common causes and solutions for the motor stopping unexpectedly during operation.
Lists common causes and solutions for the valve not reaching full open or closed positions.
Lists common causes and solutions for the motor overheating.
Lists common causes and solutions when the actuator runs but the valve does not move.
Lists common causes and solutions for the actuator operating in the incorrect direction.
Lists common causes and solutions for erratic behavior in multiple actuators.
Wiring diagrams applicable to ROM 1/A, 2, 3, 4, 5, 6 models.
Wiring schematic for 12/24V AC/DC power supply connection.
Wiring schematic for single-phase AC power supply connection.
Wiring schematic for three-phase AC power supply connection.
Key safety instructions and warranty information for the actuator.
Specifies actuator's performance class and duty cycles according to EN standards.
Details that the gear train is lubricated for the life of the actuator.
Verify torque requirements before mounting the actuator.
Specifies material and strength requirements for actuator-to-valve fixing bolts.
Critical safety warning against lifting the combined unit by the actuator.
Procedure for adjusting stop bolts for non-seating valve types to set positions.
Procedure for adjusting stop bolts for seating valve types to set positions.
Crucial safety instruction to isolate power before accessing actuator covers.
Verify that the supply voltage matches the actuator's nameplate rating.
Instructions for preparing cable entries and ensuring waterproof connections.
Connect the earth wire to the designated PE screw for safety.
Details manual operation for ROM 1/A using a hex input drive.
Critical safety warning to isolate power before manual operation.
Describes handwheel operation for ROM 2-6 models, including automatic disengagement.
Caution against using extra levers for handwheel operation to prevent damage.
Explains the function and adjustment of the local valve position indicator.
Details on adjusting travel cams and limit switches to set valve open/closed positions.
Reference to the procedure for adjusting plastic type travel cams on page 9.
Reference to the procedure for adjusting metal cams for ROM 1/A on page 10.
Reference to the procedure for adjusting metal type travel cams on page 11.
Explains output shaft rotation direction relative to the indicator for different ROM models.
Crucial safety warning to isolate power before accessing actuator covers.
Step-by-step guide for setting open and closed positions using plastic cams.
Describes adjustment for anti-clockwise closing valve types with plastic cams.
Information on optional torque switches and their factory settings.
Detailed procedure for adjusting metal cams on ROM 1/A for clockwise closing valves.
Step-by-step guide for adjusting metal cams on ROM 2-6 for clockwise closing valves.
Procedure for adjusting the potentiometer if stop bolts were adjusted or the POT slipped.
Lists common causes and solutions for the motor failing to operate.
Lists common causes and solutions for the motor stopping unexpectedly during operation.
Lists common causes and solutions for the valve not reaching full open or closed positions.
Lists common causes and solutions for the motor overheating.
Lists common causes and solutions when the actuator runs but the valve does not move.
Lists common causes and solutions for the actuator operating in the incorrect direction.
Lists common causes and solutions for erratic behavior in multiple actuators.
Wiring diagrams applicable to ROM 1/A, 2, 3, 4, 5, 6 models.
Wiring schematic for 12/24V AC/DC power supply connection.
Wiring schematic for single-phase AC power supply connection.
Wiring schematic for three-phase AC power supply connection.
