11
P/N 1011271 Rev. A 06/14
1 0012472 Inner Spring Tensioner Assy. 4
2 0012982 Conveyor Belt Assembly 37/2 2
3 0012988 Tensioner Assembly 4
4 0012989 Bun Feeder Assembly 1
5 0012990 Conveyor Cover Assembly 2
6 0021900 Idle Bearing Retainer Weldment 1
7 0021959 Cam Weldment 2
8 0021960 Base Weldment 1
9 0021962 Control Panel Weldment 2
10 0021964 End Housing Weldment 1
11 0021965 Control Housing Weldment 1
12 0100287 Platen, Grill 120V/1800W 1
13 0400147 Bushing, Shorty 7/8” 1
14 0400265 Bushing, Shorty 3/8” 4
15 0400437 Strain Relief, Rt Angle 1
16 0500464 Bearing Retainer 1
17 0503495 Bracket, Retainer Right 2
18 0503496 Bracket, Tensioner-Right 2
19 0503497 Bracket, Tensioner-Left 2
20 0503507 Bracket, Retainer Left 2
21 0506754 Panel, Electrical 1
22 0506755 Retainer, Bearing 6
23 0506756 Plate, Motor 1
24 0506763 Bracket, Trx-Conn 1
25 0506764 Chute, Bun 1
26 0700463 Power Cord,14/3 5-15P 1
27 0800455 Rod, Knob (Heel) 1
28 0800457 Rod, Knob (Crown) 1
29 0800458 Rod, Support 4
30 0800460 Shaft, Drive 2
31 0800461 Shaft, Idler 2
32 1000900 Label - Warning 1
33 1001181 Label, Crown 2
34 1001527 Label, Roundup Service 1
35 1001550 Label, Control 1
36 1001551 Label, Install 1
37 1001552 Label, Cam (Heel) 1
38 1001553 Label, Cam (Crown) 1
39 1001556 Label, Wiring Diagram 1
40 1031188 Spec Label 1
41 2100230 Bumper, Recess W/Washer 4
42 2100348 Knob, 1/4” Shaft, Push-On 2
43 2110127 Ring, Retaining 8
44 2120107 Spacer, Aluminum 2
45 2150158 Bearing, 1/2”Id X 1 1/8”Od 2
46 2150173 Sprocket, 25B12 5/16” Bore 1
Item Part No. Description Qty. Item Part No. Description Qty.
47 2150179 Sprocket, 25B14 1/2” Bore 3
48 2150186 Bearing High Temp 1/2” Bore 6
49 2150190 Sprocket, 25B28 1/2”Bore Stepped Tooth 8
50 2150258 Bearing, Idler 1
51 2150260 Spacer, Bearing 6
52 2150368 Miter Gear, 20° Pressure Angle 4
53 2150370 Chain, Drive 1
54 2180145 Cover, Bumper 4
55 3000124 Ring, Penaining 3/8” 1
56 304P105* Nut, Hex ‘Keps’ #4-40 1
57 306P121* Screw, Mach #6-32 X 3/4” 1
58 306P123* Screw, Mach #6-32 X 7/8” Slrndhd 1
59 306P130* Nut, Hex Keps #6-32 (Small Pattern) 1
60 306P156* Screw, Mach. #6-32 X 1/2” 1
61 308P115* Screw, Mach. #8-32 X 3/8” 1
62 308P143* Nut, Hex ‘Keps’ #8-32 1
63 308P144* Screw, #8-32 X 1/4” (#6 Head) 1
64 308P157* Screw, Tap 8-32 X 3/8”Lg 1
65 308P203* Screw, Tap 8-32 X 3/8” W/
Int. Tooth Washer 1
66 310P103* Screw, Mach. #10-32 X 1/4” 1
67 310P136* Screw, Mach. #10-32 X 1/4” 1
68 310P146* Nut, Hex ‘Keps’ #10-32 1
69 310P213* Screw, Phpnhd #10-16 X 3/4” Thrd Form 1
70 325P163* Set Screw, 1/4-28 X 5/16” 1
71 325P203* Washer, Spring Steel Single-Wave 1
72 338P116* Screw, Shoulder 3/8-16 X 3/8 W/
1/2 Shoulder 1
73 4000173 Gearmotor, 9 Rpm, 115V 1
74 4000210 Fan, Axial 115V 1
75 4010199 Transformer, 120 Vac/12Vac 1
76 4010245 Switch, Rocker 1
77 4030332 Thermostat, Hi-Limit 1
78 4050214 Thermocouple Type “K” (Open End) 1
79 4051010 Relay, Random Phase, Solid State-50A 1
80 4060195 Terminal Block 2
81 4060355 Terminal Block, 3-Pole 1
82 4070202 Assy-Pcb, Cfa Contact Toaster 1
83 4070213 Varistor Board 1
84 7000985 Black Wavy Silicone Belt 1
85 0021961 Conveyor Cover Weldment 2
86 0011311 Roller Tensioner Assy. 2
87 0502199 Spacer 4
88 308P145 Nut, Hex Acorn #08-32 Low Crown 1
89 7000989 Platen Sheet (Pkg. of 2) 1
*Available in Packages of 10
REPLACEMENT PARTS
