VERTICAL CONTACT TOASTER
23
P/N 1010775 Rev. J 10/13
Burger King
1 0011266 Conveyor Belt (Incl. items below) 2
0800204 1/2” Pitch Link, Small 2
0800121 3/4” Pitch Link, Large 38
2 2150117 Idler Shaft 2
3 0011491 Conveyor Cover Assy. (Incl. #29, 52, 2
61, and 76)
4 0010475 Tensioner Assy. (Incl. #40, 76, 85) 4
5 0800332 Rod, Conveyor Cover 4
6 7000207 Sprocket w/setscrew 8
7 7000199 Spacer Kit 1
8 0011444 Control Housing Cover Assy. 1
9 2150118 Drive Shaft 2
10 2100212 Handle 2
11 7000287 Control Board 1
12 7000296 Ball Bearing (Pack of 2) 1
16 7000167 Bearing & Retainer Kit 6
16A 7000224 Bearing & Retainer Kit
Includes #6 1
17 2150193 Drive Sprocket, Front 1
18 2150187 Drive Chain 1
19 0011299 Idler Sprocket & Bearing 1
20 0011300 Bracket, Idler Sprocket Assy. (Incl. 1
#91, 89, 90, 19, 87)
21 0503589 Bracket, Motor Mounting 1
22 7000240 Drive Motor Kit, Dual Frequency 1
50/60 Hz (Incl. #58)
23 2150132 Sprocket 25B14 5/16” Bore 1
(See Item 111)
24 7000882 Rocker Switch Kit 1
25 2150181 Sprocket 25B20 1/2” Bore 1
(See Item 111)
26 405K125 Relay, Solid State 2
27 4010187 Transformer 1
28 7000964 Conveyor Belt Wrap (Clip Style) 1
(Pack of 2) Mfg. No. 9210104 Only
7000416 Conveyor Belt Wrap (Pack of 2) 1
29 7000186 Roller Tensioner Assy. (Pack of 2) 1
30 0503496 Tensioner Bracket, Right 2
31 0503497 Tensioner Bracket, Left 2
32 1001006 Label, Control 1
33 1001069 Label, Dial Compression 1
34 2100253 Knob, Control 2
35 0011445 End Housing Cover Assy. 1
36 4050214 Thermocouple Assy. 1
37 0021170 Weldment, End Housing 1
38 7000249 Release Sheet (Pack of 3) -
7000250 Release Sheet (Pack of 10) -
39 0021169 Control Housing 1
40 7000121 Slide Rail Kit (Incl. Two 2
Slide Rails for Tensioners)
41 0021207 Conveyor Cam 2
42 7000176 Thermocouple Retainer Kit 2
43 4030332 High Limit Control 1
45 0503455 Tension Spring, Inner 4
46 0503590 Bracket, Motor 1
47 0700580 Wire Set (not shown) 1
48 0503385 Bun Chute 1
48A 0503895 Bun Chute (#9210204) 1
49 4030348 Auxiliary Heater, 675W/230V 2
4030349 Auxiliary Heater, 675W/208V 2
50 7000165 Auxiliary Thermocouple Kit 1
51 7000288 Platen (208V) 1
7000289 Plated (230V)
52 2100252 Tape 4
53 0503359 Bracket, Relay 1
54 0503150 Heater Clip 2
55 303P127* Hinge Pin, Belt Wrap 2
56 4060355 Terminal Block 1
57 0503533 Bracket, Auxiliary Thermocouple 1
58 4000170 Fan Blade, Motor 1
60 040K251 Strain Relief, Domestic (Incl. #63) 1
0400315 Strain Relief, International 1
61 052199* Spacer 4
62 0500464 Retainer, Bearing 1
63 040P138* Locknut, 1/2” 1
64 0011528 Heat Shield Assy. 1
65 325P163* Setscrew, 1/4-28 x 5/16” 8
66 100P864* Label, Caution Hot 1
67 308P183* Screw, Hex, #8-32 x 3/8” 2
68 304P105* Nut, #4-40, “KEPS” 4
69 406P107* Cable Tie 1
70 308P143* Nut, #8-32, “KEPS” 6
71 310P103* Screw, Hex, #10-32 x 1/4” 4
72 310P157* Washer, #10 6
73 308P101* Nut, #8-32 3
74 306P101* Nut, Hex, #6-32 2
75 306P123* Screw, #6-32 x 7/8” 2
76 308P145* Nut, Hex Acorn, #8-32 14
77 100P900* Label, Service 1
78 325P104* Washer, 1/4” 4
79 325P109* Screw, 1/4-20 x 1/2” 4
80 308P124* Screw, 1-Way, #8-32 x 1/2” 1
81 10P1022* Label, Heaters 1
82 310P180* Screw, #10-32 x 1-3/4” 4
83 308P133* Screw, #8-32 x 1/4” 1
84 308P157* Screw, Tap, #8-32 x 3/8” 20
85 308P181* Screw, Flat Hd., #8-32 x 3/8” 4
86 218P145* Cover, Leg, Bumper 4
87 331P103* Shoulder Bolt, 5/16-18 x l” 1
88 306P105* Screw, #6-32 x 1/2” 8
89 331P106* Lockwasher, 5/16” 1
90 212P118* Flat Washer, 5/16” 1
91 331P101* Nut, Hex, 5/16 x 18” 1
92 300P102* Nut, Tinnerman 2
93 210K230 Bumper, Recess Leg, 1” (Qty. of 4) 1
94 0503495 Retainer, Tensioner Bracket, RH 1
95 0503507 Retainer, Tensioner Bracket, LH 1
96 2100259 Slide Bar 4
97 4010107 Interlock Switch 1
98 0700479 Power Cord T/Lock L6-30P (Domestic) 1
0700437 Power Cord, IEC-309 (International) 1
99 306P104* Screw, #6-32 x 1/4” 6
100 4000138 Fan 1
101 0503115 Duct, Fan 1
102 1001056 Label, Crown & Heel 1
103 2120147 Leg Spacers 4
104 4060374 Ground Lug 1
105 2140152 Lubricant (not shown) 1
110 7000292 Bun Feeder Kit 1
111 7000883 Drive Motor Sprocket Kit 1
(Not shown)
* Sold only as packages of 10.
Item Part No. Description Qty.
Item Part No. Description Qty.
REPLACEMENT PARTS (continued)
