Roundup VCT-2000 - Installation and Setup; Unpacking, Assembly, and Initial Setup

VERTICAL CONTACT TOASTER
6
P/N 1010775 Rev. J 10/13
Burger King
WARNING
ELECTRICAL SHOCK HAZARD. FAILURE TO
FOLLOW THE INSTRUCTIONS IN THIS MANUAL
COULD RESULT IN SERIOUS INJURY OR DEATH.
• Electrical ground is required on this appliance.
• Do NOT modify the power supply cord plug. If
it does not fit the outlet, have a proper outlet
installed by a qualified electrician.
• Do NOT use an extension cord with this
appliance.
• The toaster should be grounded according to
local electrical codes to prevent the possibil-
ity of electrical shock. It requires a grounded
receptacle with separate electrical lines pro-
tected by fuses or a circuit breaker of the prop-
er rating.
• Check with a qualified electrician if you are
unsure if the appliance is properly grounded.
CAUTION
Bread may burn. Therefore toasters must not be
used near or below curtains or other combustible
walls and materials. Failure to maintain safe
operating distances may cause discoloration or
combustion.
Unpacking
1. Remove unit and all packing materials from
shipping carton.
2. Open the included large box. It should contain
the following:
• Bun Chute (Figure 1)
• Bun Feeder (Figure 1)
• Two Release Sheets (Figure 1)
• Owner’s Manual
• Maintenance Card
• Authorized Service Agency Directory
3. Remove all shipping tape and protective
coverings from the unit and parts.
NOTE: If any parts are missing or damaged,
contact Antunes Technical Service IMMEDIATELY
at 1-877-392-7854 (toll free in the U.S.) or 630-784-
1000.
Equipment Setup
Before placing the toaster into service, pay attention to
the following guidelines:
• Make sure power is off and the toaster is at room
temperature.
• Do NOT block or cover any openings on the unit.
• Do NOT immerse cord or plug in water.
• Keep cord away from heated surfaces.
• Do NOT allow cord to hang over edge of table or
counter.
• Connect the unit to the proper power supply.
Refer to the specification plate for the proper
voltage.
INSTALLATION
CAUTION
All electrical connections must be in accordance
with local electrical codes and any other appli-
cable codes.
Assembling the Unit
NOTE: The factory has pre-installed a Release
Sheet over the Platen (Figure 1). Verify that it is
properly in place before proceeding.
1. Remove Bun Chute and Bun Feeder from the
box and install (Figure 1).
IMPORTANT: Make sure the Heat Shield is activat-
ing the Conveyor Interlock Switch (Figure 1). The
conveyors will not rotate unless the Heat Shield is
in place and switch is activated.
CAUTION
Failure to use Release Sheets may result in
damage to the unit and loss of warranty coverage.
