Roundup VCT-2000 - Installation

VERTICAL CONTACT TOASTER
7
P/N 1010775 Rev. J 10/13
Burger King
Conveyor
Safety
Interlock
Switch
Bun Feeder
Heat Shield
Release
Sheet
Retainer
Clips
Bun Chute
Assembly
connected over
the bottom rear
support rod
Rear Conveyor
Cover Assembly
(with Roller
Tensioner)
Release
Sheet
Bun
Chute
Platen
Front
Conveyor
Belt Chain
Rear
Cleated Belt
Wrap
Front
Cleated Belt
Wrap
Front Conveyor
Cover Assembly
Roller Tensioner
Rear
Conveyor
Belt Chain
Figure 1. VCT-2000 Toaster
INSTALLATION
