OPC90 Server
PV).
Station Type For OSTN only. Specifies the Station type
code as follows:
Basic with SP
Ratio
Cascade
Basic without SP
Basic with Bias
0
Notes:
1) A line for each DEVICE block should be declared in the CSV file otherwise they will
automatically be created given the first field in the Block Name. For example Block name of
CIU4.Unit1.Block1 will automatically create a DEVICE block with the name of CIU4 at port
COM1: if a line for that device block was not already declared within the file.
2) If the DEVICE block name is missing within the block name field #1 then a DEVICE block will
be automatically created with the default name of “Device1”. Thus you can simply enter a
name for each block and they will be added under the “Device1” device. You can then
change the name of the device block in the configurator. For example, if PID1024 is specified
for field 1 then the driver will place it under the “Device1” DEVICE block.
3) Groups should not be included within the CSV file. For example, if there are 200 AIL blocks
that need to be imported into the configuration and you wanted to group them you may put
them in a single group called AREA1, for example. Block Names such as
“CIU4.AREA1.AIL1” to “CIU4.AREA1.AIL200” would be found in the CSV file. However you
do not need to add a line for the AREA1 group itself such as “CIU4.AREA1”. The group will
be automatically created.
4) If the logic state descriptors associated with digital blocks are not defined they will be
defaulted to values of “Off” and “On”.
Example1: File <OPCUnit1.csv>:
Importing the following CSV file will cause the configurator to create a default
device block called “Device1”. All the the blocks defined within this file will then
be placed under that DEVICE block. Note fields 5 to12 are omitted.
1BLKULD,DIL,1.1.4.6003,BLOCK UNIT LOAD DEC,Reset,Set
1BLCKTURBD,DIL,1.1.4.6004,BLOCK TURBINE DEC,Stopped,Running
AFDRSPD,STN,1.1.4.6009,A FEEDER SPEED STATION
1BIDINDEV,DIL,1.1.4.6029,B ID FAN INLT DMPR DEV,Off,On
CFDRSPD,STN,1.1.4.6061,C FEEDER SPEED STATION
1CFDRBCKE,RCM,1.1.4.6068,C FEEDER RUNBACK,BAD,GOOD,Stopped,Run
UNIT_GROSS_MW,AIL,1.1.4.663,UNIT GROSS MW
UNIT_GROSS_MVAR,AIL,1.1.4.664,UNIT GROSS MVAR
GEN_VOLTS,AIL,1.1.4.665,GENERATOR VOLTS
Example2: File <OPCUnit2.csv>:
The RoviSys Company Version 7.0 Page 123
