7.4 Data Acquisition Analog (DAANG)
ACCESS DESCRIPTION
The DAANG OPC90 block is used to retrieve the exception reported output from
Bailey Data Acquisition Analog blocks (function code 177).
Restrictions: This OPC90 block can be utilized with all Bailey interface types
except serial port module (SPM & CPM02).
TAGNAME TYPE
ADDR_RING VT_I2 C Bonfig/Read ailey ring address.
ADDR_NODE VT_I2 C Bonfig/Read ailey node address.
ADDR_MODULE VT_I2 C Bonfig/Read ailey module address.
ADDR_BLOCK VT_I2 C Bonfig/Read ailey block address.
MESSAGE R PVT_BSTR ead rovides the block operational message.
TAG VT_BSTR R Pead rovides the block name.
TAGLONG Read PVT_BSTR rovides the block long OPC path name.
TAGDESC R PVT_BSTR ead rovides the block descriptor.
QUALITY VT_BOOL Read C -bad). urrent quality of Bailey values (0-good, 1
COMMAND R Command attribute to request Bailey DAANG
block as follows (only valid when mode is Auto):
0
1
2
3
4
5
VT_I2 ead/Write
-Use Auto Input
-Use Calculated Input
-Suppress Alarms
-Un-suppress Alarms
-Turn Scan Off
-Turn Scan On
ALARM_CTRL Read/Write AVT_R4 larm control (see FC 177, S20).
SIG_CHANGE Read/Write S exception report
(
VT_R4 ignificant change to force an
see FC 177, S30).
TBA_PERIOD Read/Write TVT_R4 ime based alarm period (see FC 177, S31).
HI_RATE R High rate of change value (see FC 177, S32). VT_R4 ead/Write
LO_RATE R L 177, S33). VT_R4 ead/Write ow rate of change value (see FC
TSA_COUNT VT_R4 Read/Write Time ce alarm count (see FC 177, S34). sequen
OUT_HI_LIM VT_R4 R Oead UT high limit.
OUT_LO_LIM VT_R4 R Oead UT low limit.
OUT VT_R4 Read/Write Current output value received from Bailey.
EU VT_I2 R Eead ngineering Units Code.
EU_TEXT VT_BSTR R Eead ngineering Units String.
MODE Read/Write The mode of the Bailey block.
0
1
VT_I2
- Manual
- Auto
RED_CMD R rite R tion). VT_BSTR ead/W ed tag command (see red tag users sec
RED_TAG VT_BOOL R Red tag indicator (0 – no, 1 – yes). ead
RED_USERS VT_BSTR R R names or codes). ead ed tag users (current user
HI_HI_HI_ACT VT_BOOL Read High high high alarm active indicator.
HI_HI_ACT VT_BOOL Read High high alarm active indicator.
HI_ACT VT_BOOL Read High alarm active indicator.
HI_RATE_ACT VT_BOOL Read High alarm rate active indicator.
LO_RATE_ACT VT_BOOL Read Low alarm rate active indicator.
LO_ACT VT_BOOL Read Low alarm active indicator.
LO_LO_ACT VT_BOOL Read Low low alarm active indicator.
LO_LO_LO_ACT VT_BOOL Read Low low low alarm active indicator.
DVLIM VT_R4 Read/Write Deviation alarm limit.
