Rowe GrandSTAR - Figure 2-2 - Hard Drive Installed in Housing

Installing Hard Drive & Testing GrandSTAR Internet Jukebox
2-2 22022603
4. Place the hard drive in the housing (Note the hard drive connector's relationship to
the hooks) and secure it by tightening the four spring-loaded screws as shown in
Figure 2-2.
Figure 2-2 - Hard Drive Installed in Housing
POSITION DRIVE AS
SHOWN HERE
SPRING LOADED
SCREWS
