GrandSTAR Internet Jukebox Parts Catalog
22022603 8-7
Jukebox Assembly (Rear View)
Refer to Figure 8-2.
Ref. Part No. Description Qty
61184401 Jukebox Assembly (Black GrandSTAR) .................................................... Ref.
61184402 Jukebox Assembly (Red GrandSTAR)....................................................... Ref.
1 34089801 Bracket - Light Block ....................................................................................... 3
2 40942702 Frame - Filter .................................................................................................. 1
34053001 Pad - Filter (Not Shown) ................................................................................ 1
3 40965901 Bracket - Fan Filter Mounting .......................................................................... 1
4 34033901 Terminal Cover (Output Transformer) ............................................................. 1
