Rowe GrandSTAR - Top Door Assembly (Internal View)

GrandSTAR Internet Jukebox Parts Catalog
22022603 8-11
Top Door Assembly (Internal View)
Refer to Figure 8-4.
Ref. Part No. Description Qty
61183401 Door Assembly – Top (Black GrandSTAR) ................................................ Ref.
61183402 Door Assembly – Top (Red GrandSTAR) .................................................. Ref.
1 70093403 Cable Clamp - 1” ............................................................................................. 4
2 61167003 Touch Screen & Panel (See Figure 8-20) ....................................................... 1
• 22160806 Touchscreen & Monitor ................................................................................. 1 .
• 22160850 Touchscreen / Monitor Power Pack ELO Systems ....................................... 1
• 22160851 Touchscreen / Monitor Power Pack Nexview Systems ................................. 1
3 40930001 Plate, Crown Diffuser ...................................................................................... 1
4 61141301 Bracket - Hinge - LH ....................................................................................... 1
5 61183601 Bracket - Monitor Brace - LH........................................................................... 1
6 40891704 Insert-Coin (Red) ............................................................................................ 1
7 22137401 Bracket - IR Mounting ..................................................................................... 1
8 40846302 Receiver Assembly-IR .................................................................................... 1
9 34049301 Wire Block - Coin Chute .................................................................................. 1
10 22207401 Diffuser (Left Side) .......................................................................................... 1
11 34088401 Bracket-Light Diffuser ..................................................................................... 2
12 70093401 Cable Clamp - 17/32” ...................................................................................... 2
13 20554502 Clip - Cable ..................................................................................................... 4
14 34045105 CBA-Backlight LED BD - B ............................................................................. 3
15 34045104 CBA-Backlight LED BD - A ............................................................................. 3
16 40968001 Bracket - Light Lower Mid ............................................................................... 2
17 40968101 Bracket - Graphics Panel Retainer ................................................................. 2
18 61183801 Bracket - Graphics Panel Retainer ................................................................. 1
19 40968301 Bracket - Diffuser Retainer .............................................................................. 2
20 22207501 Diffuser - Right Side ........................................................................................ 1
21 22163101 Retainer - Top Door Sight Block ..................................................................... 7
22 61183701 Bracket - Monitor Brace, RH ........................................................................... 1
22 61141401 Bracket - Hinge, RH ........................................................................................ 1
Items not shown:
34054604 Harness Assembly - Door Speaker ................................................................. 1
40960207 Cable Assembly - Door and Service ............................................................... 1
22215005 Cable Assembly - Module, Rowelink Controller to IR ..................................... 1
22212811 Cable Assembly - Ribbon - SR 1 Right Crown ................................................ 1
22212812 Cable Assembly - Ribbon - SR 1 Left Crown .................................................. 1
22212813 Cable Assembly - Ribbon - SR 1 Upper Lighting ............................................ 1
22212814 Cable Assembly - Ribbon - SR 1 Middle Lighting ........................................... 1
22212815 Cable Assembly - Ribbon - SR 1 Lower Lighting ............................................ 1
Note: For additional harness part numbers, refer to the Wiring Diagrams in Section 7.
