GrandSTAR Internet Jukebox Parts Catalog
22022603 8-5
Jukebox Assembly (Front View)
Refer to Figure 8-1.
Ref. Part No. Description Qty
61184401 Jukebox Assembly (Black GrandSTAR) .................................................... Ref.
61184402 Jukebox Assembly (Red GrandSTAR)....................................................... Ref.
1 61183401 Door Assembly – Top (Black) See Figure 8-3, Figure 8-4, Figure 8-5 ...... Ref.
61183402 Door Assembly – Top (Red) See Figure 8-3, Figure 8-4, Figure 8-5 ......... Ref.
2 61184501 Lower Door Assembly (Gold)
See Figure 8-6, Figure 8-7 (Used on Red GrandSTAR) .......................... Ref.
61184502 Lower Door Assembly (Silver)
See Figure 8-6, Figure 8-7 (Used on Black GrandSTAR) ........................ Ref.
3 40854006 Bill Inlet ........................................................................................................... 1
40916101 Blockout - Bill Acceptor (If Bill Acceptor must be removed) ............................ 1
34031003 Label Blockout (Attach to Bill Acceptor Blockout) ........................................... 1
To Next Page
