GrandSTAR Internet Jukebox Parts Catalog
22022603 8-9
Top Door Assembly (External View)
Refer to Figure 8-3.
Ref. Part No. Description Qty
61183401 Door Assembly – Top (Black GrandSTAR) ................................................ Ref.
61183402 Door Assembly – Top (Red GrandSTAR) .................................................. Ref.
1 40830806 Speaker-MID Frequency ................................................................................. 2
2 40830901 Speaker-Tweeter (3") ...................................................................................... 2
3 40968201 Panel (Outside) ............................................................................................... 1
40969001 Graphics .......................................................................................................... 1
40968202 Panel (Inside) .................................................................................................. 1
4 22207201 Panel-Graphics (Left) ...................................................................................... 1
5 22207101 Panel-Graphics (Right) ................................................................................... 1
6 61183501 Top Door - Black/Silver ................................................................................... 1
61183502 Top Door - Red/Gold ....................................................................................... 1
7 61140203 Grill, Speaker-Top Door - Silver (Black GrandSTAR) .................................... 2
61140201 Grill, Speaker-Top Door - Gold (Red GrandSTAR) ........................................ 2
8 34043502 Medallion ......................................................................................................... 1
70135517 Palnut .............................................................................................................. 4
9 61140701 Diffuser "Crown", CD100 ................................................................................. 1
Note: For harness part numbers, refer to the Wiring Diagrams in Section 7.
