GrandSTAR Internet Jukebox Parts Catalog
22022603 8-13
Top Door Assembly (Internal — Top and Side View)
Refer to Figure 8-5.
Ref. Part No. Description Qty
61183401 Door Assembly – Top (Black GrandSTAR) ................................................ Ref.
61183402 Door Assembly – Top (Red GrandSTAR) .................................................. Ref.
1 22162801 Bracket - Crown LED (Side) ............................................................................ 2
2 34045102 Circuit Board Assembly - Crown, Pilaster LED BL, W (Black GrandSTAR) .... 2
34045106 Circuit Board Assembly - Crown, Pilaster LED Y, R (Red GrandSTAR) ......... 2
3 34045103 Circuit Board Assembly - Crown, Pilaster LED R, G (Black GrandSTAR) ...... 2
34045107 Circuit Board Assembly - Crown, Pilaster LED Y, R (Red GrandSTAR) ......... 2
4 22164101 Brace - Top Door ............................................................................................ 2
5 61141201 Hinge - Top Door ............................................................................................ 1
6 40929901 Bracket - Crown LED (Center) ........................................................................ 1
7 22165002 Support - Circuit Board ................................................................................. 22
8 34024501 Lock Bolt ......................................................................................................... 1
9 70163214 Cylinder Lock .................................................................................................. 1
10 22169401 Link ................................................................................................................. 2
11 25181701 Spring - Tension .............................................................................................. 2
Note: For harness part numbers, refer to the Wiring Diagrams in Section 7.
