Folding system description
Instruction manual Folding system Page 29 of 100
USB-B port
Power supply
connection
9-pin D-sub
connector
The following connectors are located on the rear of the left cover cap:
- Connector for 24 V power supply unit
- USB Type B connector (for connection to Fold Manager)
ROWE VarioFold Compact connectors, rear of left cover cap
The front of the right cover cap contains the connector for linking the
online Folding system with a printer.
ROWE VarioFold Compact connector, front of right cover cap
