Operation
Instruction manual Folding system Page 84 of 100
If any paper remains i the folding machine after this, loosen the
mounting screws and remove the support brackets.
Carefully remove the infeed roller and remove any remaining paper.
Reinstall the infeed roller and secure it with the support brackets and
corresponding mounting screws.
Front delivery tray,
below the feed table
Rear delivery tray
Upper infeed roller
Right mounting screw and
support bracket
Left mounting screw and
support bracket
