5
B
V-Rake Models Discussed
All information in this manual pertains to the
Wheel V-Rakes Figure B-1 lists the Models covered in
this manual.
Figure B-1: Model Numbers and
Descriptions
Model Model
Number Description
ULT 17 17 Wheel Rake
ULT 19 19 Wheel Rake
ULT 25 25 Wheel Rake
ULT 27 27 Wheel Rake
Model Number and Serial Number
of Your Rowse Ultimate V-Rake
For future reference, record below the model
number and serial number of your Rowse V-Rake.
This information is stamped into the frame on the
top of the left front wing of your V-Rake. See Figure B-2.
Model Number: _________________________
Serial Number: __________________________
Serial Number and Model Number
(stamped into the frame)
FRONT
