ULTIMATE V-RAKE RMT PARTS LIST
TRANSPORT BAR ASSEMBLY
Ref. Part No. Description Qty.
1 ULT2005 Bracket, “A” Frame Transport 17 & 25 only 1
2 ULT2006 Wing Transport Stabilizer Assembly 2
2A ULT20061 Stabilizer, Inner Wing Transport 2
3 ULT20062 Stabilizer, Outer Wing Transport 2
4 75C400HCS5Z Bolt, 3/4”-10 x 4” HHC G5 2
5
6 75CNFH5Z/NE Nut, 3/4”-10 G5 2
7 107-100 Zerk, 1/4”-28 Str. Lub 2
8 RM-2112 Pin, 3/4” x 2-3/4” Clevis 2
9 111-20 Hair Pin Clip #6 4
10 50C300HCS5Z Bolt, 1/2”-13 x 3” HHC G5 2
11 50CNNE0Z/NE Nut, 1/2”-13 Lock 2
12 RM-2109 Steering Rod End 2
13 75FNFJ0Z Nut, 3/4”-16 Hex NF Jam 2
14 OG-5145 Spring, Pin Lock1 1
15 18R150PCO0Z Cotter Key, 3/16” x 1-1/2” 1
16 RC185U Pin, Spring Assembly 2
17 75C300HCS5Z Bolt, 3/4”-10 x 3 HHC G5 2
18 75CNNE0Z/NE Nut, 3/4”-10 Lock 2
19 RM2112 3/4 x Picker Pin 2
