ULTIMATE V-RAKE RMT PARTS LIST

TONGUE ASSEMBLY

Ref. Part No. Description Qty.

1 ULT2010 Tongue, Ultimate 17 & 25 1

2 ULT2410 Tongue, Ultimate 19 & 27 1

3 ULT2011 Hitch, 2-5/16” 1

4 SWL198DTSM Jack Assembly, 7000 Lb. 1

5 ULT2012 Hydraulic Hose Transport Cradle 1

6 RM-2109 Steering Rod End 2

7 75FNFJ0Z Nut, 3/4”-16 Hex Jam NF 2

8 ULT20701 Clamp, Hose 5” 2

9 37CNNE0Z/NE Nut, 3/8”-16 Lock 2

10 75C200HCS5Z Bolt, 3/4”-10 x 2” HHC G5 8

11 75NLOC0Z Washer, 3/4” Lock 8

12 75CNFH5Z Nut, 3/4”-10 HHC G5 8

13 844905060-BX Hydraulic Hose, 1/2” x 60” 2-Wire 3 w/valve, 5 w/o valve

14 8010-4 Pioneer Male Tip, 1/2” “Poppet” 3 w/valve, 5 w/o valve

15 RM-2373 Ball, 2-5/16” x 1-1/4” x 3” Shank 1

16 100FNFH0Z Nut, 1”-14 Hex NF, for Ball 1

17 100NLOC0Z Washer, 1” Lock 1

18 ULT2420 Hydraulic Tube, Tongue 19 & 27 3 w/valve, 5 w/o valve

19 ULT20101 Hydraulic Tube, Tongue 17 & 25 3 w/valve, 5 w/o valve
