ULTIMATE V-RAKE RMT PARTS LIST
PLATFORM (CENTER FRAME)
Ref. Part No. Description Qty.
1 ULT2000 Center Frame, Platform 1
2 ULT2020 Pin Only, 3” Platform 2
3 ULT2015 Pin Kit for Small Clevis on Platform 2
4 50C150HCS5Z Bolt, 1/2”-13 x 1-1/2” HHC G5 2
5 50NLOC0Z Washer, 1/2” Lock 2
6 ULT1011B Retainer, Pin, Arm 1 Hole 2
7 75NLOC0Z Washer, 3/4” Lock 2
8 75C200HCS5Z Bolt, 3/4”-10 x 2” HHC G5 10
9 50N200WFH0Z Washer, 1/2” x 2” Fender, Hvy Steel 2
10 75CNFH5Z Nut, 3/4-10 G5 14
11 700-0823-4007 Remote Valve Only 1
12 700-0824-4012 Remote Valve with Switch Box 1
13 37C400HCS5Z Bolt, 3/8”-16 x 4” HHC G5 2
14 75NLOC0Z Washer, 3/4” Lock 14
15 37CNNE0Z/NE Nut, 3/8”-16 Lock 2
16 210-029 Street Elbow, 3/8” O-Ring to 1/2” Pipe 90 Deg. (included with Remote Valve) 8
17 0107-8-8 Swivel, 1/2” Str. 3
18 PMR 12 Restrictor, 1/2” 1-way 1
19 841305000 Nipple, 1/2” x Close 1
20 844905012-BX Hydraulic Hose, 1/2” x 12” 2-wire 2
21 210-027 Adapter, 3/8” O-Ring to 1/2” pipe (included with Remote Valve) 2
22 843102500 Cross, 1/2” Pipe, Female 1
23 844905024-BX Hydraulic Hose, 1/2” x 24” 2-wire 2 Std., 1 Opt.
24 844905048-BX Hydraulic Hose, 1/2” x 48” 2-wire 7
25 844905036-BX Hydraulic Hose, 1/2” x 36” 2-wire 2
26 ULT20011 Hydraulic Tube, Center Frame 60” 3
27 844905030-BX Hydraulic Hose, 1/2” x 30” 2-wire 3
28 844905072-BX Hydraulic Hose, 1/2” x 72” 2-wire 1
29 839300050 Restrictor, 1/2” 2-way Swivel 2
30 210-127 Plug, 3/8” O-Ring (included with Remote Valve) 2
