ULTIMATE V-RAKE RMT PARTS LIST
TEE ASSEMBLY RMT
Ref. Part No. Description Qty.
1 ULT2001 Tee, Center Frame 1
2 ULT20015 Poly Strip, 3/16” x 5” x 48” 2
3 ULT20016 Poly Strip, 1/4” x 5” x 48” 1
3A ULT20017 Poly Strip, 1/4” x 5” x 48” with Groove 1
4 31C62KFCE Bolt, 5/16” x 5/8” Flat Head Socket 24
5 ULT2015 Pin Kit for Small Clevis on Platform 2
6 ULT2003 Arm Strut (Tee to Positioning Arm) 2
7 SS-4856-24 Bushing, 1-1/2” x 1-3/4” x 1-1/2” Bronze 8
8 111-100 Zerk, 1/4”-28 90 Deg. NFT 4
9 50N200WFH0Z Washer, 1/2” x 2” Fender, Hvy. Steel 2
10 50NLOC0Z Washer, 1/2” Lock 2
11 50C150HCS5Z Bolt, 1/2”-13 x 1-1/2” HHC G5 2
12 HD4024 Cylinder, 4” x 24” 1
13 WR1027 Pin, 1” x 2-3/8” Headed 2
14 18R200PC00Z Cotter Key, 3/16” x 2” 2
15 100N150AMB0/10G Washer, 1” x 1-1/2” x 10 Ga. AR
100N150AMB0/14G Washer, 1” x 1-1/2” x 14 Ga. AR
16 9405-8-8 Street Elbow, 1/2” 90 Deg. with Swivel 2
AR=As Required
