Rowse Ultimate V-Rake - Arm, Positioning, Right

61
ULTIMATE V-RAKE RMT PARTS LIST
POSITIONING RIGHT ARM
Ref. Part No. Description Qty.
1 ULT2030 Arm, Positioning 1
2 ULT2041 Arm, 4” x 4” 1
3 ULT2040 Arm, 3” x 3” 1
4 HD2751 Cylinder, 2-3/4” x 1” x 12-1/4” Master/Slave 1
ULT2042 Optional Adjustable Link, Toe In 1
5 9405-8-8 Street Elbow, 1/2” 90 Deg with Swivel 5
6 844905048-BX Hydraulic Hose, 1/2” x 48” 2-Wire 1
7 844905072-BX Hydraulic Hose, 1/2” x 72” 2-Wire 1
8 ULT6010 Pin, Cylinder Transport 2
9 100N150AMB0/10G Washer, 1” x 1-1/2” x 10 Ga AR
100N150AMB0/14G Washer, 1” x 1-1/2” x 14 Ga AR
10 18R200PC00Z Cotter Key, 3/16” x 2” 2
11 111-20 Hair Pin Clip #6 2
12 ULT6020 Transport Bar, Upper 1
13 SS-4856-24 Bushing, 1-1/2” x 1-3/4” x 1-1/2” Bronze 4
14 111-100 Zerk, 1/4”-28 90 Deg. NFT 3
15 ULT20401 Poly Strip, 3/16” x 3” x 29-1/2” 1
16 ULT20402 Poly Strip, 1/4” x 3” x 29-1/2” 1
16A ULT20403 Poly Strip, 1/4” x 3” x 29-1/2” with groove 2
17 31C62KFCE Bolt, 5/16” x 5/8” Flat Head Socket 8
18 ULT2015 Pin Kit for Small Clevis on Platform 1
19 50N200WFH0Z Washer, 1/2” x 2” Fender, Hvy. Steel 1
20 50NLOC0Z Washer, 1/2” Lock 1
21 50C150HCS5Z Bolt, 1/2”-13 x 1-1/2” HHC G5 1
22 SS-96104-48 Bushing, 3” x 3-1/4” x 3” Bronze 4
23 ULT20701 Clamp, Hose 5” 5
24 37CNNE0Z/NE Nut, 3/8” Lock 5
25 ULT1011A Retainer, Leg Top, 2 Holes 1
26 ULT2035R Hydraulic Tube, Arm Positioning, Right 3
27 ULT1011B Retainer, Pin Arm, 1 Hole 1
28 75NLOC0Z Washer, 3/4” Lock 1
29 75C200HCS5Z Bolt, 3/4”-10 x 2” HHC G5 1
30 ULT2035 JIC, 5/8” x 3” Electrical Cord Holder 5
31 ULT2074 Top Pointer 1
AR=As Required
